Phase 1-phase

Max. PV input power 8,200 W

Rated output power 8,200 VA/8,200 W

Max. solar charging current 160A

PV INPUT (DC)

Rated DC voltage/max. DC voltage 360/500 VDC

Start-up voltage/initial feed-in voltage 90VDC/120VDC

MPPT voltage range 90-450VDC

Number of MPPT trackers/max. input current 1/27A

GRID OUTPUT (AC)

Rated output voltage 200/230/240 VAC

Output voltage range 195-253 V

Rated output current 35.6 A

Power factor >0.99

Grid frequency range 49-51±1 Hz

EFFICIENCY

Max. conversion efficiency (DC/AC) 98%

OUTPUT POWER

Full load 8,200 W

Max. main load 8,200 W

Max. load of the 2nd output (battery mode) 2,733 W

Main load cut-off voltage 44 VDC

Main load recovery voltage 48 VDC

AC INPUT

AC Start-up Voltage/Auto Restart Volt. 120 VAC-140 VAC/180 VAC

Acceptable input voltage range 90-280 VAC or 170-280 VAC

Max. AC input current 40A

Rated operating frequency 50/60 Hz

Surge power 16,400 W

PV INPUT (DC)

Max. DC voltage 500 VDC

MPPT voltage range 90VDC-450VDC

Number of MPPT trackers/max. input current 1/27A

OUTPUT IN BATTERY MODE (AC)

Rated output current 48 VDC

Waveform Pure sine wave

Conversion efficiency (DC/AC) 94%

Charger

Supported battery types: lead-acid /VRLA/AGM/Deep Cycle/Gel/Flooded/Tubular/Lithium-Ion

Rated battery voltage 48 VDC

Max. charging current from solar panels 160A

Max. charging current from the AC grid 150A

Operating parameters

Operating temperature from 0°C to 50°C

Storage temperature from -15°C to 60°C

Humidity from 5% to 95% relative humidity (non-condensing)

Physical characteristics

Product size, D x W x H (mm) 537x390x130

Product weight (kg) 14.2

Communication interface RS232, RS485

Dimensions: 537×390×130 mm
